LOAD CELL INDICATOR FOR TESTING MACHINE CONTROL


CE

Standard reference indicator specially designed to display the 4 signals generated by the 3115F-12390 load cell. It is designed for the control of concrete testing machines according to EN12390-4 and DIN 51302-2 standards.

- Compliant with EN 12390-4 and DIN 51302-2 standards
- 4 independent displays
- Resolution: 5 digits
- Robust industrial housing
- Digital output: RS-485


AVAILABLE OPTIONS

o analogue output: 0...10 V or 4...20 mA
Add to basket
for quotation

INDI-12390
Type (-) 4 x strain-gauge input
Input range (-)
4 x ± 24 mVDC / 4 x ± 240 mVDC
Combined error (non-linearity + hysteresis) (% F.S.*) < 0.1
Sensor excitation (-) 4 x 10 VDC
Display (-) 4 x 5 digits (14.2 mm)
A/D converter (-)
16 bits
Converter rate (-) 20/s
Service temperature range (°C)
0...+50
Storage temperature range (°C)
-40...+60
Power supply (-)
85...250 VAC (60 VA)

*F.S. : Full Scale.
Specifications subject to change without notice.
