CRANE OVERLOAD PROTECTION ELECTRONICS
Crane overload protection electronics with 3 set-points and display to be installed on a front panel.
- RS-232, RS-485 or fieldbus capabilities
- NEMA 4X / IP67 (transparent protection cover + Option "COVER PAX")
- rail DIN adaptor
- power supply: 48 VAC / 24 VDC (see INDI-BOY2 and DISP-BOYP2 products)
- also available with industrial metallic housing (see CRANE-BOY / CRANE-BOYP products)
o Easy and intuitive calibration
o Display of hoisted load and input signal
o Internal monitoring system of load cell integrity and load limitation electronics (fail safe)
AVAILABLE OPTIONS
- Analogue output 4 (0)...20 mA or 0...10 V- RS-232, RS-485 or fieldbus capabilities
- NEMA 4X / IP67 (transparent protection cover + Option "COVER PAX")
- rail DIN adaptor
- power supply: 48 VAC / 24 VDC (see INDI-BOY2 and DISP-BOYP2 products)
- also available with industrial metallic housing (see CRANE-BOY / CRANE-BOYP products)
| INDI-BOY | INDI-BOY12 | DISP-BOYP | DISP-BOYP12 | |
|---|---|---|---|---|
| Type (-) | Load limiter for single load cell | Load limiter for single load cell | Load limiter for single load cell | Load limiter for single load cell |
| Input range (-) | ± 24 mVDC / ± 240 mVDC | ± 24 mVDC / ± 240 mVDC | 20 mA (-2 to +26 mA) | 20 mA (-2 to +26 mA) |
| Sensor excitation (-) | 10 VDC @ 125 mA max | 10 VDC @ 125 mA max | 24 VDC ± 5 % @ 50 mA max. | 24 VDC ± 5 % @ 50 mA max. |
| Display (-) | 5 digits (14.2 mm) | 5 digits (14.2 mm) | 24 VDC ± 5 % @ 50 mA max. | 5 digits (14.2 mm) |
| Accuracy (% F.S.*) | 0.1 | 0.1 | 0.1 | 0.1 |
| A/D converter (-) | 16 bits | 16 bits | 16 bits | 16 bits |
| Converter rate (-) | Up to 20 readings /s | Up to 20 readings /s | Up to 20 readings /s | Up to 20 readings /s |
| Service temperature range (°C) | 0...+50 | 0...+50 | 0...+50 | 0...+50 |
| Storage temperature range (°C) | -40...+60 | -40...+60 | -40...+60 | -40...+60 |
| Power supply (-) | 85...250 VAC, 50/60 Hz (15 VA) | 11...36 VDC (11 W), 24 VAC (15 VA) | 85...250 VAC, 50/60 Hz (15 VA) | 11...36 VDC (11 W), 24 VAC (15 VA) |
| Qty of relay (-) | 3 | 3 | 3 | 3 |
| Relay type (-) | "Form A"- potential free | "Form A"- potential free | Form A - potential free | Form A - potential free |
| Contact rating (-) | 3 A @ 250 VAC / 30 VDC | 3 A @ 250 VAC / 30 VDC | 3 A @ 250 VAC / 30 VDC | 3 A @ 250 VAC / 30 VDC |
| IP rating (-) | IP54 | IP54 | IP54 | IP54 |
*F.S. : Full Scale.
** : 5 VDC @ 65 mA max (jumper selectable).
*** : IP rating for front panel only.
**** : we recommend the INDI-BOY2 and DISP-BOYP2 for use in 24 VDC.
Specifications subject to change without notice.
